Release Note

Updated: October 31 2019

Ver. 0.11 - October 31 2019

The overview of the new features are as follows.

New boundary conditions

Following two boundary conditions have been added:

  • Symmetry plane
  • Boundary face mapping

By using the boundary face mapping, you can set periodic boundary conditions to the model.

Setting Boundary face mapping between upper and lower faces
Setting Boundary face mapping between upper and lower faces
Calculation result on the Boundary face mapping (flow velocity)
Calculation result on the Boundary face mapping (flow velocity)

Improvements of GUI

Various GUI improvements have been made, including the ability to adjust the width of each column on the main screen.

You can change the width of each panel by dragging the border.
You can change the width of each panel by dragging the border.

In addition, the problem that an wrong value can be input with GUI was corrected.
